COBHAM Sailor 6390 Assembly Instruction

406390A-00500 Sailor 6390 Navtex Receiver
406390A Navtex Receiver
97-138962-A Assembly Instruction
22 May 2013 Page 5 of 9
7.3. Mounting of ground screws.
Place Washer Serrated Lock part no. 53-200166-004
on Screw part no. 51-205286-408.
Figure 10
Place Washer part no. 53-206184-004 on Screw part
no. 51-205286-408.
Figure 11
Mount 4 x Screws with washers from above on chassis
for navtex.
#T1: El-screwdriver 0.8 Nm ± 0.1 Nm Torx 20.
Rotational speed: 600 ±50 rpm.
Figure 12
