Livewell Pump Box (Optional)
The livewell pump box furthers the efficiency and effectiveness of your livewell system and is located directly under the
lazarette located in the rear cockpit. Water enters the pump box through two scoops located on the hull. As the box fills with
water any and all air is expelled from the box. This makes it so that only water (No Air) enters the pumps or the livewell,
preventing any air locking issues. This both increases the life of your baitfish by further reducing wave action in your livewell
tanks and greatly extends the life of your livewell pumps.
The pump box contains three pumps labeled 1, 2, and 3. Pump 1 fills your port livewell tank while pump 2 fills your starboard
livewell tank, with pump 3 acting as a back up if either pump should fail. To use pump 3 turn the PVC ball valve into to open
position and locate the three-way valve located just aft of the PVC ball valve. Turn this valve either way to direct water into the
port livewell tank or the starboard live well tank.
***In case of emergency to prevent water from flowing into the pump box close the ball valves located in the bilge***
