Cobra 19 MINI User Manual

13
12
English
Intro Operation Customer
Assistance
Warranty
Notice
Main Icons
Secondary Icons
Caution Warning
Installation
Customer
Assistance
Operation
Intro Operation Customer
Assistance
Warranty
Notice
Main Icons
Secondary Icons
Caution Warning
Installation
Customer
Assistance
LCD Display Function Setting
KEY BP Beep on (default): turn on beep
oF: turn off beep
ROG BP
Roger Beep Sound oF, Tone settings 01 - 06
(End of transmission sound) oF: (default) turn off
roger beep
VOX L
VOX Level (Sensitivity) Level: 01 - 09
Default: 03
VOX T VOX Delay Time Level: 01 - 09
Default: 01
RF.GAIN RF Gain Control Levels
: 03, 06, 09 - 48
oF (default) RF gain off
TOTSET Time Out Timer oF, 01 - 10 minutes
Default: 05
PWRAUTO
Automatic Power On on (default): Auto power on
oF: Manual power on
FW VER Firmware Version Displays 2-digit
Firmware Version
RESET See Reset to Factory
Default Section (page 8)
Menu Options
1. Push and release the MENU button to access the menu
(see menu options in the Table below).
2. Turn the POWER button or press the microphone UP or DN
buttons to choose the desired function.
3. Push and release the POWER button on the selected option,
then rotate the knob to the desired setting and the POWER
button again to save the setting.
Selecting the Menu
Selecting the Menu
Intro Operation
Frequency Ranges
This unit features advanced Phase Lock Loop (PLL) circuitry providing
complete coverage of all 40 CB channels.
NOTE
All 40 channels support AM and FM operating modes.
CB
Channel
Channel Frequency
in MHz
1 26.965
2 26.975
3 26.985
4 27.005
5 27.015
6 27.025
7 27.035
8 27.055
9 27.065
10 27.075
11 27.085
12 27.105
13 27.115
14 27.125
15 27.135
16 27.155
17 27.165
18 27.175
19 27.185
20 27.205
CB
Channel
Channel Frequency
in MHz
21 27.215
22 27.225
23 27.255
24 27.235
25 27.245
26 27.265
27 27.275
28 27.285
29 27.295
30 27.305
31 27.315
32 27.325
33 27.335
34 27.345
35 27.355
36 27.365
37 27.375
38 27.385
39 27.395
40 27.405
Mode
AM/FM
AM/FM
AM/FM
AM/FM
AM/FM
AM/FM
AM/FM
AM/FM
AM/FM
AM/FM
AM/FM
AM/FM
AM/FM
AM/FM
AM/FM
AM/FM
AM/FM
AM/FM
AM/FM
AM/FM
Mode
AM/FM
AM/FM
AM/FM
AM/FM
AM/FM
AM/FM
AM/FM
AM/FM
AM/FM
AM/FM
AM/FM
AM/FM
AM/FM
AM/FM
AM/FM
AM/FM
AM/FM
AM/FM
AM/FM
AM/FM

Cobra 19 MINI Specifications

General

Output power	4 W
Frequency range	- MHz
Channels quantity	40 channels
Squelch attenuator	Yes
Supported radio bands	AM, FM
Product type	Car CB radio
Product color	Black
Housing material	-
Cables included	Power
Input voltage	12 V
Display type	LCD

Weight and Dimensions

Depth	110.9 mm
Width	103.8 mm
Height	24.8 mm
Package depth	65 mm
Package width	128 mm
Package height	189.9 mm
Package weight	620 g
