INSTALLATION MANUAL 4625 - 4627 CAN/PLIP
11
J-21 and J-22 Engine crank inhibition: to get the maximum security level to the system connect the two wires as shown
in the electrical diagrams to prevent the engine starter running. During the cranking phase, measure the value of the current in the
circuit that has been interrupt, to make sure that it does not exceed the technical specifi cations of the product. Install an additional
relay if required.
J-23 CDL lock negative output (only for 4627): low power control signal to lock central door locking. Activated by the
Cobra remote control (optional) - (see electrical diagram F).
J-24 CDL unlock negative output (only for 4627): low power control signal to unlock central door locking. Activated by
the Cobra remote control (optional) - (see electrical diagram F).
* See the “FUNCTIONS PROGRAMMING TABLES” manual.
24 ways connector J pin-out for PLIP confi gurations
J-1 Positive perimetric input: to be connected to the vehicle roof lamp.
J-2 Negative perimetric input: to be connected to the vehicle roof lamp.
J-3 Logic blinker output: make the connection if required by the specifi c vehicle PLIP installation sheet.
J-4 Positive input for CDL motor opening signal: to connect as indicated in the specifi c vehicle PLIP installation sheet
or in the product installation guide for PLIP applications available on the web under Application manuals.
J-5 Negative input for CDL opening switch signal: to connect as indicated in the specifi c vehicle PLIP installation sheet
or in the product installation guide for PLIP applications available on the web under Application manuals.
J-6 Negative input for CDL closing switch signal: to connect as indicated in the specifi c vehicle PLIP installation sheet
or in the product installation guide for PLIP applications available on the web under Application manuals.
J-7 +15/54 connection: to be connected to a ignition key ON positive signal. The positive signal must be feeded while starting
the vehicle and when the engine is ON.
J-8 GND connection: the ground must be connected to a factory earth point or directly to the negative pole of the battery.
J-9 12V connection (+30): the positive supply must be connected to a vehicle positive connection point upstream of the fuse
box. Fit a 15A fuse as close as possible to the connection point.
J-10 Cobra BUS: communication line for the connection of compatible Cobra sirens and sensors.
J-11 and J-12 Do not connect.
J-13 Negative input for additional modules: to be used as a triggering input for the connection of compatible Cobra modules.
J-14 Negative output for modules: active when the system is armed. To be used for the connection of compatible Cobra
modules.
J-15 Horn/loudspeaker negative output: to program in line with the connected device. See electric diagrams and
functionalities programming tables. The output set automatically as per selected device, for horn choose also fi x or intermittent.
J-16 Blinker inhibition positive input: to connect as indicated in the specifi c vehicle PLIP installation sheet or in the product
installation guide for PLIP applications available on the web under Application manuals.
J-17 Negative input to enter in programming procedure/to connect bonnet pushbutton: if connected to
ground the system will enter in the programming procedure for all applications not able to detect the original bonnet pushbutton. If the
siren is a wireless one this input must not be used for the bonnet pushbutton connections. For wired siren or loudspeaker this input
must be used for the connection of the bonnet pushbutton as indicated in the specifi c vehicle PLIP installation sheet.
J-18 Positive input for CDL motor closing signal: to connect as indicated in the specifi c vehicle PLIP installation sheet
or in the product installation guide for PLIP applications available on the web under Application manuals.
J-19 Logic blinker feedback input or power blinker output: make the connection if required by the specifi c vehicle
PLIP installation sheet.
J-20 Power blinker output: make the connection if required by the specifi c vehicle PLIP installation sheet.
