CONNECTIONS
Audio and Video Signal Input/Output
Through the player’s AV function, you can view programs from an external signal device as well as transmit
the player’s AV signal to an outer receiver.
Fig1 - AV signal input
Fig2 - AV signal output
Match the color of plugs to the colo• r of connectors when use AV cabels.
Refer to the owner’s manual of the external device as well.•
Make sure all necessary connections have been properly made before connect •
the power.
If the player will not be used for a long period of time, disconnect the power and •
remove the battery from the remote control.
External Receiver
AV Signal Device
To Next Page
