Coby TFTV2224 - Page 13

7
Figure. Cable connections
ComponentInput
S-VideoInput
AVInput
NOTE:
Besuretohaveallnecessaryconnectionsproperlydonebeforeconnectthepowersupply.1.
WheninputtheAVsignal,refertothemanualoftheexternalsourcesaswell.2.
NOTE:
WesupplytheAVcableand thepower cord
withthisproduct.
Thewhite/redplugof theAVcableisforthe
audioconnectionandtheyellowplugforthe
videoconnection.
Thewhite/redplugof theAVcablecanalso
beusedseparatelytoinputthe audiosignal
intheS-video/Componentconnection.
Cable Connections
