Coby TFTV2224 - Cable Connections

6
Figure. Cable connections
Antenna/Power Connection
ConnectTVRFsourcestotheantennaport.TVRFsignalsinclude:receivingantenna/CATVnet.You1.
canuse75Ohmcoaxialcabletoconnectoutdoorantenna.
Insertoneendofthesuppliedpowercordtotheplayer’spowerjackandtheotherendtothe110-240V2.
ACwalloutlet.
Compoent Input (Y Cb/Pb Cr/Pr)
Thecomponentportiscapableofacceptinghigh-denitionsignalsfromstandardvideosources.(e.g.,cable/
satelliteboxes,DVDplayers,VCRs,etc.)
ConnecttheY/Pb/Prportbythecomponentcabletoinputthevideosignal.1.
Connect“R”"L"portbythesupplyAVcabletoinputtheaudiosignal.Thered/whiteplugoftheAVcable2.
isfortheaudioconnecitonandtheyellowplugforthevideoconnection.
S-Video Input
TheS-Videoportiscapableofacceptingsignalsfromstandardvideosources.(e.g.,cable/satelliteboxes,
DVDplayers,VCRs,etc.)
ConnecttheS-VideoportbytheS-Videocabletoinputthevideosignal.1.
ConnecttheAUDIO-L/RportbythesupplyAVcabletoinputtheaudiosignal.2.
AV Input
TheCVBSportiscapableofacceptingsignalsfromstandardvideosources(e.g.,cable/satelliteboxes,DVD
players,VCRs,etc.)
ConnecttheVIDEOportwiththeyellowplugofthethesuppliedAVcable.1.
ConnecttheL/Rportwiththered&whiteplugofthesuppliedAVcabletoinputtheaudiosignal.2.
VGA Input
TheVGAportoftheTViscapable ofacceptinghigh-denitionsignalsfromcomputerswithaVGAoutput
jack.Whenusedasacomputermoniter,connecttheVGAjackandthePCAudioInjackwitha15-PinD-Sub
cableanda3.5mmstereoaudiocable.
HDMI Input
HDMI(HighDenitionMultimediaInterface)isanewtypeofconnectionthattransmitsdigitalaudioandvideo
signalssimultaneouslyoverasinglecable.AHDMIcableisrequiredfortheHDMIconnection.
TheseHDMIinputconnectorsarecapableofreceivingvideoatresolutionsupto1080p(1080-progressive).
Cable Connections
External AV Source
Settheunitintotherelativeinputmode
toenablethesignalpass.
