internal and under the counter components
equipment
The dispenser is
equipped with two
stand-by modes:
1. Power Saver Mode
If the dispenser is inactive for
120-minutes the touchscreen
will go dark. Simply tap the
touchscreen anywhere to
wake it up.
2. Locked Mode
Lock the dispenser by
pressing the lock icon in the
top right corner of the crew
dashboard. This mode locks
the touch screen and prohibits
dispensing during non-
operating hours. Choose to
lock manually or set an
automated time window.
Power Switch
The power (on/o) switch is
located on the right-hand side
underneath a square plastic
flap. CAUTION! DO NOT
POWER OFF unless told to do
so by a Coca-Cola Senior
Technician or as instructed for
safety when cleaning the ice
bin (refer to page 17).
Ingredient cartridge
Cartridge tray
Brand identification strip
Power switch
HFCS sweetener
CO
2
tank
Power Switch
Cartridge Tray
