Cocoon IT315007 - Product Components Identification

8
After Sales Support
1300 663 907
Model Number IT315007
customercare@winplus.com.au
1
2
3
Product Overview
1.1 Voyager Quadcopter
1.2 Remote Control - Buttons
1. Camera 2. Propeller Guards 3. Landing Skids
1. High/Low Speed Button
2. Antenna
3. Indicator
4. Left Control Stick
5. Photo/Video Switch
6. Left Tuning Switch
7. On/O Switch
8. Trick Button
9. Right Control Stick
10. Forward/Back Trim
11. Mode Switch
12. LCD Display
5
6
11
12
7
8
1
2 3
4
9
10
