Product Overview
1.3 Remote Control - Display
1. Signal Indicator
2. Mode Indicator
3. Turn Left
4. Throttle Lever Fine-
tuning
5. Throttle
6. Right
7. Backward
8. Turn Left/Right Fine-
tuning
9. High/Low Speed
Indicator
10. Control Battery Level
11. Turn Right
12. Forward/Backward Fine-
tuning
13. Throttle
14. Left
15. Sideways Fine-tuning
1 9
2 10
5 13
3 11
6 14
8
7 15
4 12
