Code 3 Pursuit User Manual

920-0505-00 Rev. B
Page 4 of 12
Input Wiring Functions for Network Junction Box
36 Inch and Shorter Pursuit Lightbars
Input (Wire Color) Function Description Flash Pattern/Rate
Green/Black Level 1 Level 1 Emergency Mode. Sweep Rev
White/Black Level 2 Level 2 Emergency Mode. Dual End Rotate
Red/Black Level 3 Level 3 Emergency Mode. Pursuit
Orange/Black Takedown Forward facing lower light heads steady burn. Steady
Yellow Left Alley Left facing lower light heads steady burn. Steady
Purple Right Alley Right facing lower light heads steady burn. Steady
Grey
TD/Alley
Flash
Forward, Left, and Right lower light heads ash. Single 150
Brown
Driver Side
Cut
Triggers Driver Side Corners and Alley Positions to turn off for
8 seconds.
Not Available
Blue/Black Rear Cut Triggers all rear facing and rear corners to turn off. Not Available
Pink Front Cut Triggers all front facing and front corners to turn off. Not Available
Green Cruise
All upper corner light heads will steady burn in a dimmed
state.
Cruise Low
Blue Dim
Dim can be applied to any feature and pattern except for TD
and Alley.
Dim Low
Orange
Arrowstik
Flash
Rear lower light heads ash. Single 150
Additional functions not included as part of default conguration
Alley Flash Left and Right lower light heads ash. Single 150
TD Flash Forward lower light heads ash. Single 150
Aux Customer Dened
Left Arrow Rear facing lower light heads illuminate in the left direction. Building Fast
Right Arrow Rear facing lower light heads illuminate in the right direction. Building Fast
Center Out
Rear facing lower light heads illuminate from the center then
outward direction.
Building Fast
California
Steady
Light head steady burns for California T13 Compliance. CA Steady
Any of the wires above not used to control the lightbar should be capped or otherwise insulated from
accidental contact with power sources.
