Code 3 Pursuit User Manual

920-0505-00 Rev. B
Page 8 of 12
Replacement Parts and Accessories (See previous page for exploded view of lightbar)
Description Part Number
Lenses Upper
1. Upper Outboard Lens - Red 250-0340-04
Upper Outboard Lens - Blue 250-0340-22
Upper Outboard Lens - Clear 250-0340-03
Upper Outboard Lens - Amber 250-0340-02
2. Upper Center Lens Short - Red 250-0341-04
Upper Center Lens Short - Blue 250-0341-22
Upper Center Lens Short - Clear 250-0341-03
Upper Center Lens Short - Amber 250-0341-02
3. Upper Center Lens Long - Red 250-0342-04
Upper Center Lens Long - Blue 250-0342-22
Upper Center Lens Long - Clear 250-0342-03
Upper Center Lens Long - Amber 250-0342-02
Inner Panels
4. Outboard Inner Panel 220-0602-00
5. Center Long Inner Panel 220-0603-00
6. Center Short Inner Panel 220-0604-00
Lenses Lower
7. Lower Outboard Lens - (Clear only) 250-0343-03
8. Lower Center Short Lens - (Clear only) 250-0344-03
9. Lower Center Long Lens - (Clear only) 250-0345-03
LED Modules Upper
10. Upper Level Light Head - Red 155-0420-03
Upper Level Light Head - Blue 155-0420-01
Upper Level Light Head - White 155-0420-02
LED Modules Lower
11. Lower Level Light Head - White 155-0421-02
Lower Level Light Head - Red 155-0421-04
Lower Level Light Head - Blue 155-0421-22
Lower Level Light Head - Amber 155-0421-00
Sign Head
12. Illuminated sign 155-0424-00
Light Head Mtg Brkts
13. Outboard end bracket 220-0612-00
14. Lower light head bracket 220-0598-00
Controller
15. M5-LED32 controller 155-0419-00
Screws
Lens screw (M5 x 30mm socket cap - not shown) 323-0050-00
Internal screw (M5 x 10mm Phillips head - not shown) 323-0051-00
CAUTION!
When replacing LED modules it is important to note the output from the controller for the module
being replaced, because damage can occur from incorrect module conguration. Details regarding
conguration of a specic lightbar can be obtained from the manufacturer.
