Flasher Set-Up
Changing flash patterns for the STD ( SW2) or Interclear mode ( SW3)
The flash pattern can be changed (while the LED lightheads are on) by pressing the designated switch on the
PCB and releasing.
Patterns - (all patterns are alternating):
1. Single Flash (180 FPM) - Default primary pattern
2. Single Flash (120 FPM)*
3. Double Flash (120 FPM)* - Default interclear pattern
4. Triple Flash (120 FPM)*
5. Single Flash (90 FPM)*
6. Double Flash (90 FPM)*
7. Triple Flash (90 FPM)*
8. Single Flash (75 FPM)*
9. Double Flash (75 FPM)*
10. Triple Flash (75 FPM)*
11. Quad Flash (75 FPM)*
12. Cycle Flash (8, 9, 10, 11, Repeat)
* - California Title 13 compliant (as of 11/07)
Dip Switch Setup for Side Lights and Setting Left Forward and Left Angled Light to Steady Burn
Place position 3 of the DIP switch located on the PCB into the “ON” position. This will enable steady burn of
the left forward and angled facing lights when the front lights are on.
Sidelights
Placing position 1 of the DIP switch ( SW1) into the “ON” position assigns the front side lights LFS and RFS to
the Rear group of lights.
Placing position 2 of the DIP switch into the “ON” position assigns the rear side lights to the Front group of
lights.
OFF OFF
Default- Front Sided grouped with Front Lights,
Rear Sides grouped with Rear Lights.
ON OFF
Front/Rear Sides grouped with Rear Lights
OFF ON
Front/Rear Sides grouped with Front Lights
ON ON
Front Sided grouped with Rear Lights,
Rear Sides grouped with Front Lights.
Flasher Position 1 & Position 2 Dipswitch Table
Cruise Input
Placing +12V on the Cruise input will cause the two front facing lights and two rear facing lights to dimly steady
burn.
Turn Signal
Placing +12V on the Turn Signal input will cause the auxiliary turn signals to function. This function, when
attached to the motorcycle harness will repeat the standard motorcycle turn signal.
Brake Tail
A modulated DC input will cause the tail light to function. A steady +12V input will cause the brake light to
function. This function, when attached to the motorcycle harness, will repeat the standard motorcycle tail or
brake function. The light will flash quickly three times and remain on during the brake function.
Connect the Photocell Input connector of the wiring harness to the photocell assembly. The photocell will turn
off the auxilary light output with low ambient light. In case a photocell option is not desired, attach the jumper
wire included with the rear LED mounting plate in place of the photocell.
Photocell Input
