Code 3 XTP Series Installation And Operation Instructions

Page 5 of 8
PATTERN
GROUP
PATTERN NO
FLASH PATTERN
RED WIRE
LED Primary Color
UP 1&3, DN 5&7
SYNC
Complies with
FLASH PATTERN
WHITE WIRE
LED Secondary Color
UP 2&4, DN 6&8
SYNC
Complies with
PATTERN
GROUP
PATTERN NO
FLASH PATTERN
RED & WHITE WIRE (to-
gether)
LED Primary Color
UP 1&3, DN 5&7
LED Secondary Color
UP 2&4, DN 6&8
SYNC
Complies with
5
38
Trpl 75FPM Ph1 Color
1&3&5&7 only
yes SC
Trpl 75FPM Ph1 Color
2&4&6&8 only
yes S
5
34
Trpl 75FPM Rt-Lt 1&5 Alt
4&8
yes S
39
Trpl 75FPM Ph2 Color
1&3&5&7 only
yes SC
Trpl 75FPM Ph2 Color
2&4&6&8 only
yes S 35
Trpl 75FPM Rt-Lt 3&7 Alt
2&6
yes S
40
Trpl 75FPM Alt
1&3&5&7 with 2&4&6&8
yes SC
Trpl 75FPM Alt 2&4&6&8
with 1&3&5&7
yes S 36
Trpl 75FPM Diagonal 1&7
Alt 4&6
yes S
41
Trpl 75FPM Up-Dn 1&3
Alt 5&7 only
yes S
Trpl 75FPM Up-Dn 2&4
Alt 6&8 only
yes S 37
Trpl 75FPM Diagonal 3&5
Alt 2&8
yes S
42
Trpl 75FPM Up-Dn 1&3
Alt 6&8 only
yes S
Trpl 75FPM Up-Dn 5&7
Alt 2&4 only
yes S 38
Trpl 75FPM CCW 1&3&5&7
Alt 2&4&6&8
no
43
Trpl 75FPM Rt-Lt 1&5
Alt 3&7
yes S
Trpl 75FPM Rt-Lt 2&6
Alt 4&8
yes S 39
Trpl 75FPM CCW 2&4&6&8
Alt 1&3&5&7
no
44
Trpl 75FPM Diagonal
1&7 Alt 3&5
yes S
Trpl 75FPM Diagonal
2&8 Alt 4&6
yes S 40
Trpl 75FPM CW 1&3&5&7
Alt 2&4&6&8
no
45
Trpl 75FPM CCW
1&3&5&7 only
no
Trpl 75FPM CCW
2&4&6&8 only
no 41
Trpl 75FPM CW 2&4&6&8
Alt 1&3&5&7
no
46
Trpl 75FPM CW
1&3&5&7 only
no
Trpl 75FPM CW
2&4&6&8 only
no
6
47
Quad 75FPM Ph1 Color
1&3&5&7 only
yes SC
Quad 75FPM Ph1 Color
2&4&6&8 only
yes SC
6
42
Quad 75FPM Rt-Lt 1&5 Alt
4&8
yes S
48
Quad 75FPM Ph2 Color
1&3&5&7 only
yes SC
Quad 75FPM Ph2 Color
2&4&6&8 only
yes SC 43
Quad 75FPM Rt-Lt 3&7 Alt
2&6
yes S
49
Quad 75FPM Alt
1&3&5&7 with 2&4&6&8
yes SC
Quad 75FPM Alt
2&4&6&8 with 1&3&5&7
yes SC 44
Quad 75FPM Diagonal 1&7
Alt 4&6
yes S
50
Quad 75FPM Up-Dn
1&3 Alt 5&7 only
yes S
Quad 75FPM Up-Dn 2&4
Alt 6&8 only
yes S 45
Quad 75FPM Diagonal 3&5
Alt 2&8
yes S
51
Quad 75FPM Up-Dn
1&3 Alt 6&8 only
yes S
Quad 75FPM Up-Dn 5&7
Alt 2&4 only
yes S 46
Quad 75FPM CCW
1&3&5&7 Alt 2&4&6&8
no
52
Quad 75FPM Rt-Lt 1&5
Alt 3&7
yes S
Quad 75FPM Rt-Lt 2&6
Alt 4&8
yes S 47
Quad 75FPM CCW
2&4&6&8 Alt 1&3&5&7
no
53
Quad 75FPM Diagonal
1&7 Alt 3&5
yes S
Quad 75FPM Diagonal
2&8 Alt 4&6
yes S 48
Quad 75FPM CW 1&3&5&7
Alt 2&4&6&8
no
54
Quad 75FPM CCW
1&3&5&7 only
no
Quad 75FPM CCW
2&4&6&8 only
no 49
Quad 75FPM CW 2&4&6&8
Alt 1&3&5&7
no
55
Quad 75FPM CW
1&3&5&7 only
no
Quad 75FPM CW
2&4&6&8 only
no
7
56
Quad 150FPM Ph1
Color 1&3&5&7 only
yes S
Quad 150FPM Ph1 Color
2&4&6&8 only
yes S
7
50
Quad 150FPM Rt-Lt 1&5 Alt
4&8
yes S
57
Quad 150FPM Ph2
Color 1&3&5&7 only
yes S
Quad 150FPM Ph2 Color
2&4&6&8 only
yes S 51
Quad 150FPM Rt-Lt 3&7 Alt
2&6
yes S
58
Quad 150FPM Alt
1&3&5&7 with 2&4&6&8
yes S
Quad 150FPM Alt
2&4&6&8 with 1&3&5&7
yes S 52
Quad 150FPM Diagonal 1&7
Alt 4&6
yes S
59
Quad 150FPM Up-Dn
1&3 Alt 5&7 only
yes S
Quad 150FPM Up-Dn
2&4 Alt 6&8 only
yes S 53
Quad 150FPM Diagonal 3&5
Alt 2&8
yes S
60
Quad 150FPM Up-Dn
1&3 Alt 6&8 only
yes S
Quad 150FPM Up-Dn
5&7 Alt 2&4 only
yes S 54
Quad 150FPM CCW
1&3&5&7 Alt 2&4&6&8
no
61
Quad 150FPM Rt-Lt
1&5 Alt 3&7
yes S
Quad 150FPM Rt-Lt 2&6
Alt 4&8
yes S 55
Quad 150FPM CCW
2&4&6&8 Alt 1&3&5&7
no
62
Quad 150FPM Diagonal
1&7 Alt 3&5
yes S
Quad 150FPM Diagonal
2&8 Alt 4&6
yes S 56
Quad 150FPM CW 1&3&5&7
Alt 2&4&6&8
no
63
Quad 150FPM CCW
1&3&5&7 only
no
Quad 150FPM CCW
2&4&6&8 only
no 57
Quad 150FPM CW 2&4&6&8
Alt 1&3&5&7
no
64
Quad 150FPM CW
1&3&5&7 only
no
Quad 150FPM CW
2&4&6&8 only
no
For patterns that meet SAE J595 Class1 requirements for Red, Blue, Amber, and White, see S in chart!
For patterns that meet California Title 13 Class B requirements for Red, Blue, and Amber, see C in chart!
For patterns that meet ECE R65 Class 2 Cat X (day & night) requirements for Red, Blue, Amber see E2 in chart!
Flash Patterns XTP4DS Multi Color (Continued):
