Code 3 XTP Series Installation And Operation Instructions

Page 6 of 8
For patterns that meet SAE J595 Class1 requirements for Red, Blue, Amber, and White, see S in chart!
For patterns that meet California Title 13 Class B requirements for Red, Blue, and Amber, see C in chart!
For patterns that meet ECE R65 Class 2 Cat X (day & night) requirements for Red, Blue, Amber see E2 in chart!
Flash Patterns XTP4DS Multi Color (Continued):
PATTERN
GROUP
PATTERN NO
FLASH PATTERN
RED WIRE
LED Primary Color
UP 1&3, DN 5&7
SYNC
Complies with
FLASH PATTERN
WHITE WIRE
LED Secondary Color
UP 2&4, DN 6&8
SYNC
Complies with
8 65
Modulation Flash Color
1&3&5&7 only
no
Modulation Flash Color
2&4&6&8 only
no
9 66
Modulation Flash Up-Dn
1&3 Alt 5&7 only
no
Modulation Flash Up-Dn
2&4 Alt 6&8 only
no
10 67
Modulation Flash Rt-Lt
1&5 Alt 3&7
no
Modulation Flash Rt-Lt
2&6 Alt 4&8
no
11 68
Modulation Flash CCW
1&3&5&7 only
no
Modulation Flash CCW
2&4&6&8 only
no
12 69
Modulation Flash CW
1&3&5&7 only
no
Modulation Flash CW
2&4&6&8 only
no
13 70
Steady Burn 1&3&5&7
only
no
Steady Burn 2&4&6&8
only
no
The XTP series light head has been thoroughly factory tested. If any of the the device functions fail, please check the following:
1. Be sure the power source is activated, then check all connections both positive and ground at the light head (to assure no open or shorted
circuits).
2. Permanently connecting the Blue programming wire to ground will disable the light head, no matter what the programmed ash pattern.
3. If the Dim function does not operate, verify the Blue wire is connect to positive.
4. If the sync function is not being used and the light head is functioning erratically, verify the Yellow wire is not connected to positive.
Troubleshooting:
Replacement Parts and Accesories:
Description XTP4DS
Bezel Black Plastic CZXTP4DSBZL
Bezel Chrome Plastic XTP4DSCHMBZ
