Page 3 of 8
A variety of ash patterns may be chosen for the light head. The Multi Color light heads are split vertically as separate lighted areas that may
be chosen to operate alternately. The areas are denoted by: Primary color 1&3 (color1 on the left side and color3 on the right, typically the
same color) and Secondary color 2&4 (color2 on the left side and color4 on the right, typically the same color). This allows for patterns that
ash right-left using various multiple color combinations.
A separate ash pattern may be assigned for the power wires red, white, or both connected together and the pattern operated depending
which wire or wires are energized. Power the red or the white wires (or both together) then use the pattern select blue wire (touch to ground)
to select the chosen ash pattern from the list below. See the legend at the top of the pattern list for compliance with various standards.
Pattern Select Operation:
The light head ash pattern may be changed by touching the Blue wire to ground for the following intervals (while the light head is ashing):
NOTE: The blue wire must be disconnected from any voltage when not activating DIM nor changing ash patterns.
- When the light head signal becomes steady, disconnect the Blue wire and the ash pattern will increment by one pattern.
- When the light head signal becomes steady, then goes o󰀨, disconnect the Blue wire and the ash pattern will decrement by one pattern.
- When the light head signal becomes steady, then goes o󰀨, then becomes steady again, disconnect the Blue wire and the ash pattern will
reset to the factory default pattern.
- When the light head signal becomes steady, then goes o󰀨, then becomes steady again, then goes o󰀨 again, disconnect the Blue wire and
the ash pattern will become set to the steady burn mode.
Flash Patterns:
PATTERN
GROUP
RED WIRE
LED Color
1&3
WHITE
WIRE LED
Color 2&4
RED & WHITE
WIRE LED
Color 1&3,
Color 2&4
FLASH PATTERN
SYNC
Complies
with
0
1-Default Cycle Flash Color 1&3 no
1-Default Cycle Flash Color 2&4 no
1-Default Cycle Flash Color 1&3 and Color 2&4 no
1
2 2 Single 75FPM Ph1 Color 1 Sync Color 3 yes SC
3 3 Single 75FPM Ph2 Color 1 Sync Color 3 yes SC
4 Single 75FPM Ph1 Color 1 Alt Color 4 yes
5 Single 75FPM Ph2 Color 1 Alt Color 4 yes
2 6 Single 75FPM Ph1 Color 2 Sync Color 4 yes SC
3 7 Single 75FPM Ph2 Color 2 Sync Color 4 yes SC
4 4 8 Single 75FPM (Color 1 Sync Color 3) Alt (Color 2 Sync Color 4) (Phase 1) yes SC
5 5 9 Single 75FPM (Color 1 Sync Color 3) Alt Color 2 Sync Color 4) (Phase 2) yes SC
6 6 10 Single 75FPM Color 1 Alt Color 2 Alt Color 3 Alt Color 4 yes
2
7 11 Single 375FPM Ph1 Color 1 Sync Color 3 yes
8 12 Single 375FPM Ph2 Color 1 Sync Color 3 yes
13 Single 375FPM Ph1 Color 1 Alt Color 4 yes
14 Single 375FPM Ph2 Color 1 Alt Color 4 yes
7 15 Single 375FPM Ph1 Color 2 Sync Color 4 yes
8 16 Single 375FPM Ph2 Color 2 Sync Color 4 yes
9 9 17 Single 375FPM (Color 1 Sync Color 3) Alt (Color 2 Sync Color 4) (Phase 1) yes
10 10 18 Single 375FPM (Color 1 Sync Color 3) Alt (Color 2 Sync Color 4) (Phase 2) yes
11 11 19 Single 375FPM Color 1 Alt Color 2 Alt Color 3 Alt Color 4 yes
3
12 20 Double 75FPM Ph1 Color 1 Sync Color 3 yes SC
13 21 Double 75FPM Ph2 Color 1 Sync Color 3 yes SC
22 Double 75FPM Ph1 Color 1 Alt Color 4 yes
23 Double 75FPM Ph2 Color 1 Alt Color 4 yes
12 24 Double 75FPM Ph1 Color 2 Sync Color 4 yes SC
13 25 Double75FPM Ph2 Color 2 Sync Color 4 yes SC
14 14 26
Double 75FPM (Color 1 Sync Color 3) Alt
(Color 2 Sync Color 4) (Phase 1)
yes SC
15 15 27
Double 75FPM (Color 1 Sync Color 3) Alt
(Color 2 Sync Color 4) (Phase 2)
yes SC
16 16 28 Double 75FPM Color 1 Alt Color 2 Alt Color 3 Alt Color 4 yes
For patterns that meet SAE J595 Class1 requirements for Red, Blue, Amber, and White, see S in chart!
For patterns that meet California Title 13 Class B requirements for Red, Blue, and Amber, see C in chart!
For patterns that meet ECE65 Class1 Cat X (night only )requirements for Red, Blue, Amber, see E1 in chart!
For patterns that meet ECE65 Class2 Cat X (day & night) requirements for Red, Blue, Amber, see E2 in chart!
