Code Blue CB 1-s - Table of Contents

CB 1 Series
Table of Contents
Administrator Guide
Section
Section Title
Page #
2
Introduction
4
CB1 Model Photos
5
3
Safety Information
6
4
Installation Instructions
7
Tools Required
7
Getting Started
8
Anchor Bolt Kit
9
Deck Mount Kit
10
Base Gasket
11
Overhead Camera Mount
12
Equipment Ring
13
Dome Top
14
S-1000 & S-1050 Strobe/Beacon
15
5
Programming
16
6
Power Requirements
17
7
Wiring Diagram
21
100-240 AC / DC or 24V AC @ 60 Watt or 24V DC
21
PoE DIN Rail Power System | 48V DC 12.96w or 25.5w
22
NightCharge® 120-240V AC @ 5 Amps w/ Area Light | 12VDC 10
Amps
23
NightCharge® 120-240V AC @ 3 Amps NO Area Light | 12VDC 10
Amps
24
120-277V AC DIN Rail Power w/ 150W Audio Paging | 12 or 24V
DC 10 Amps Max
25
Multi-Tap Transformer (Power Brick) 110-347VAC
26
8
Locating Unit Serial Numbers
27
9
Maintenance Schedule
28
10
Warranty
30
11
Download Information
31
12
Legal and Regulatory Information
32
GU-157-FF
page 3 of 31
