8
11.0 - CR1100 Hole Mounting Pattern
10.0 - Reader ID and Firmware Version
To nd out the Reader ID and Firmware version, open a text editor program
(i.e., Notepad, Microsoft Word, etc.) and read the Reader ID and Firmware
conguration barcode.
Reader ID and Firmware
Note: Code will periodically release new firmware for CR1100, which requires CortexTools2 to update. There are also a number of
drivers (VCOM, OPOS, JPOS) available on the website. For access to the latest drivers, firmware, and support software, please visit our
the product page on our website at codecorp.com/products/code-reader-1100.
NOTE 1:
Locating holes are 2 mm (0.08”)
diameter, hole depth is 1.5 mm
(0.06”)
NOTE 2:
Mounting inserts are M3 x 0.5
internal thread, 3.8 mm (0.15”)
length.
10.4 mm (0.41”)
15.5 mm (0.6”)
34.1 mm (1.34”)
31.1 mm (1.23”)
30.2 mm (1.19”)
27.0 mm (1.06”)
D032078 _02 CR1100 User Manual
<RD><RR MD=”CR1100” /></RD><RD><RR SN=”1060000003” /></RD><RD><FW VS=”1.1.4” /></RD><RD><LC GL=”” /></RD>
You will see a text string indicating your rmware version and CR1100 ID number.
example: <RD><RR MD=”CR1100” /></RD><RD><RR SN=”1060000003” /></RD><RD><FW VS=”1.1.4 ” /></RD><RD><LC GL=”” /></RD>
Model Number Serial Number Firmware
Version
Number
License Part
Number (if there
is any)
