34
5 Accessories
G500 Series
Secure the cutter cover using the screws provided for this purpose.
Pass the labels through the guides.
Close the printing mechanism.
Accessories
034
Place the cutter cover
Locking
Locking
SCREWS
Through the cutter module
Through the label guides
LABEL GUIDES
