COE S7 - Main Hydraulic Circuit

TANK
Circuits
31
HEAD ROLL CYL
2.5 x 3.5
6000 VALVE
SHAKE MOTOR
IN-OUT CYL
2 x 30
TANK
CLAMP CYL
4 x 20
CLAMP
LOCK VALVE
HEAD LIFT CYL
5 x 8 (2005-2010)
(2) 3.5 x 8 (2011-)
BULK HEAD
TANK
TANK
UN-LOCK
PILOT
S7 main hydraulic circuit
MAIN PUMP
Shake Sequence
Clamp Pressure
Valve.
COE DECEL VALVE
HUSCO 5000 VALVE
LIFT & ROLL
Counterbalance
valve on dual lift
cylinder machines.
IN-OUT CLAMP SHAKE
BULK HEAD
BULK HEAD
Return
Pressure
Working
CFD TO DUAL COOL
PUMP DRIVE MOTOR
