Parts
43
Shaker head parts
DRAWING ON PAGE 18
No. DESCRIPTION PART NUMBER QTY
TH-7 SHAKER HEAD
1 TH7-CASE MAIN WELD MENT 1
2 TH7-CLAMP ARM WELDMENT 1
3 SLIP SLING LONG 24” 13750 2
4 SLIP SLING SHORT 24” 13751 2
5 OVAL SHAKER PAD 70 DUROMETER 24” 14389 2
6 WATER MANIFOLD 4 PORTS 24” 13749 2
7 MANIFOLD HOSE BARB 4MJ-4BARB 11539 2
8 SLING RETAINER BAR 8 HOLE 3526 2
9 SLING STUD 5/8" X 3" 3764 16
10 SLING STUD NUTS 5/8" FINE THREAD NYLOCK 1682 16
11 15" ENERGY WHEEL 8V (FLAT WHEEL) 14368 1
12 18" ENERGY WHEEL 8V (V WHEEL) 14369 1
13 ENERGY WHEEL BEARINGS (SPHERICAL) 14361 4
14 ENERGY PIN 11308 1
15 ENERGY PIN BOLT 11306 1
16 ENERGY PIN BOLT NUT 15008 1
17 ENERGY PIN WASHERS 11312 2
18 ENRGY PIN TAPER WEDGES 11311 2
19 OUTER BEARING SPACERS 14359 2
20 ENERGY WHEEL SPACER (CENTER) 14358 1
21 EXTERNAL SEAL PLATES 14254 4
22 INNER O-RING FOR SEAL PLATE (1 PER SEAL PLATE) 14364 4
23 FASTENER EXTERNAL SEAL PLATES (6 PER) 14246 24
24 REVERSING IDLER PULLEY 8V 10” N 2123 1
25 REVERSING IDLER BEARING 14793 1
26 BEARING CAP REVERSING IDLER 8V 2274 1
27 WASHER REVERSING IDLER N 2275 1
28 REVERSING IDLER STAND 1234 1
29 ALIGNMENT IDLER PULLEY 13510 1
30 ALIGNMENT IDLER BEARINGS 1013 1
31 ALIGNMENT IDLER SNAP RING 11317 1
32 ALIGNMENT IDLER STAND (3BOLT) 12594 1
33 DRIVE SHEAVE 12” (ALMOND) 10883 1
34 DRIVE SHEAVE 13" (WALNUT & PECAN) 12359 1
35 DRIVE BELT 8V (HEAVY DUTY) 14636 1
36 TAPER LOCK FOR DRIVE PULLEY 1 3/4” 2116 1
37 SHAKER MOTOR VOAC F12-110 5602 1
38 ADAPTER MB-MJ90-12-8 928 1
39 SHAKER MOTOR HOSE SPLIT FLANGES SIZE 20 12805 2
40 PIN CLAMP ARM (REAR MAIN PIVOT) 11268 1
41 CASTLE NUT FOR CLAMP ARM PIN 13240 2
42 REAR CLAMP ARM PIN INSERT KEYED 14038 1
43 REAR CLAMP ARM PIN BUSHING TOP 14037 1
44 REAR CLAMP ARM PIN BUSHING BOTTOM 14036 1
45 ENERGY PIN SEALING CAP UPPER & LOWER 1817 2
46 SEALING CAP O-RINGS (1 PER) 12535 2
