7. Insert the rubber seal.
Note: The seal can only be installed in the correct orientation.
8. Remount the front cover. Observing the tightening sequence below, tighten all four screws to 9 Ncm using a
torque wrench.
PHILLIPS PAN HEAD M2 X 6MM
Note: Tighten in sequence. Torque limit: 9 Ncm (0.8 in-lbs).
31
Setting Up Your DataMan 360 Reader
