Cognex DM363X - Table of Contents

Table of Contents
Legal Notices 2
Table of Contents 3
Symbols 5
About the DataMan 360 Reader 5
Supporting Documentation 5
DataMan 360 Series Accessories 6
Lens Options 6
Lens Covers 8
External Lights (Red LED) 9
Laser Aimers 9
High Power Illumination Accessories 9
Cables 10
Power Supplies 11
Mounting Brackets 11
DataMan 360 Systems 12
Setting Up Your DataMan 360 Reader 13
Reader Layout 13
Dimensions 15
Installing the Lens 17
Installing an M12 Lens with Manual Focus 17
Installing a Liquid Lens 19
Installing the 24 mm Liquid Lens Module with DM360-HPIL-RE-01 or DM360-HPIL-RE-P-01 21
Installing a C-Mount Lens 23
Connecting External Illumination to DataMan 360 26
Installing a Filter 28
External Light Mounting Brackets 32
Setting Focus 34
Liquid Lens 34
Manual Focus Lens 36
Focus Feedback 36
Best Practices 37
Field of View and Reading Distances 38
Reading Distance and Field of View (DataMan 360 Readers with a 10.3 mm Liquid Lens) 38
Reading Distance and Field of View (DataMan 360 Readers with a 16 mm Lens) 39
Reading Distance and Field of View (DataMan 360 Readers with a 19 mm Lens with a Liquid Lens) 40
Reading Distance and Field of View (DataMan 360 Readers with a 24 mm Lens with Liquid Lens) 41
Reading Distance and Field of View (DataMan 360 Readers with a 25 mm Lens) 42
DataMan 360 Series Specifications 44
DataMan 360 Series Imager Specifications 45
LED Wavelengths 45
Illumination Options 46
Using Your DataMan 360 Reader 48
Installing DataMan Software and Connecting the Reader 48
Troubleshooting an Ethernet Connection 48
3
Table of Contents
