DataMan 360 Series Specifications
Specification DataMan 360 Reader
Weight 165 g
Operating
Temperature
0ºC — 40ºC (+32ºF — 104ºF)
Storage
Temperature
-10ºC — +60ºC (+14ºF — +140ºF)
Maximum
Humidity
< 95% (non-condensing)
Environmental IP65 (with cable or protection cap attached to all connectors, front cover properly installed)
LED Safety IEC62471: red illumination: Exempt Risk Group, blue and white illuminations: Risk Group 1 (Low-
Risk). No further labeling is required.
RS-232 RxD, TxD according to TIA/EIA-232-F
Codes 1-Dbarcodes: Codabar, Code 39, Code 128, and Code 93, Interleaved 2 of 5, MSI, Pharma, GS1
DataBar, Postal, UPC/EAN/JAN
2-D codes: Data Matrix
TM
(IDMax and IDQuick: ECC 0, 50, 80, 100, 140, and 200), QR Code and
microQR Code, MaxiCode, DotCode, Aztec Code, RSS/CS
Stacked codes: PDF 417, MicroPDF 417
Discrete I/O
operating limits
HS Output 0,1,2,3 I
MAX
50 mA
R
MIN
@ 12 VDC 200 Ω
Input 0 (Trigger) V
IH
±15 — ±28 V
Input 1,2,3 V
IL
0 — ±5 V
I
TYP
@ 12 VDC 2.0 mA
@ 24 VDC 4.2 mA
Power Supply
Requirements
24 V +/- 10%
Options:
l Internal illumination (non-HPIL*): 250 mA maximum, 5 W
l Internal illumination (HPIL*): 2.2 A maximum, 6 W
l External illumination: up to 1.2 A average, 45 W, peak current according to illumination,
these values depend on the illumination and its configuration
Supplied by LPS or NEC class 2 only
*HPIL denotes one of the DM360-HPIL-RE or DM360-HPIL-RE-P accessories
Light Connector Current load up to 1.05 A average
Ethernet Speed 10/100
Duplex Mode Full duplex or half duplex
