Mounting the Sensor
Firmly mount the sensor so that the laser is perpendicular to the motion of travel. The accuracy and reliability of your 3D
images relies on the three-dimensional coordinate system defined by the position of the sensor and the movement of
objects that pass within its view.
Feature Description
1 A three-dimensional coordinate system where the origin is at the center of the laser plane on
the surface of movement.
2 For best results, movement should be perpendicular to the laser plane.
Multiple sensors should be mounted coplanar with each other, spaced apart so that there is sufficient overlap between
the laser plans to cover the required distance.
The sensor offers three mounting options:î
21
