4.4 Technical data table
Data
Units
CADI 6 CADI 11 CADI 14
Product identication codes G20
GCC1HKKF GCC1MKKF GCC1PKKF
Product identication codes G31
GCC1HLKF GCC1MLKF GCC1PLKF
Countries of destination
ES - PT - IT - FR - BE
Gas category
II2H3+ (ES-PT-GB) / II2HM3+ (IT) / II2E+3+ (FR) / I2E+ (BE) / I3+ (BE)
Maximum heat capacity
kW 11.8 21.1 26.8 Q
Minimum heat capacity
kW 6.3 8.1 10.7 Q
Maximum heat capacity
kW 10.4 18.9 23.8
Minimum heat capacity
kW 5.4 7.0 9.3
Performance at max. power
% 87 87 87
Burner injectors G20
n. x Ø 14 x 0.82 24 x 0.85 28 x 0.85
Gas supply pressure G20
mbar 20 20 20
Maximum gas delivery G20
m3/h 1.25 2.23 2.84
Minimum gas delivery G20
m3/h 0.67 0.86 1.13
Burner injectors G230
n. x Ø 14 x 0.95 24 x 0.95 28 x 0.95
Gas supply pressure G230
mbar 20 20 20
Maximum gas delivery G230
m3/h
0.97 1.73 2.20
Minimum gas delivery G230
m3/h
0.52 0.66 0.88
Burner injectors G31/G30
n. x Ø
8 x 0,49
6 x 0,47
18 x 0.49
6 x 0.47
18 x 0.50
10 x 0.47
Gas supply pressure G31/G30
mbar 37 37 37
Max. gas delivery G31/G30
kg/h 0.92 1.64 2.08
Min. gas delivery G31/G30
kg/h 0.49 0.63 0.83
NOx emission class
- 6 (<56 mg/kWh) NOx
Max. operating pressure
bar 10 10 10 PMS
Min. operating pressure
bar 0.2 0.2 0.2
DHW delivery ∆25º
l/min 6.0 10.8 13.6
DHW delivery ∆30º
l/min 5.0 9 11.4
Degree of protection
IP X4D
Supply voltage
V/Hz 3V =
Absorbed electrical power
W / / /
Empty weight
Kg 8.5 9.50 13.50
Type of unit
B11BS
