Coleman CT200U User Manual

1. Install front Fork Assembly by
inserting the 10mm steering bolt
through the assembly in the
following order:
Top bracket, Small 10mm
Washer, Steering Neck, Large
10mm Washer, Bottom Bracket,
Large 10mm Washer, Lock Nut
FRONT FORK INSTALLATION
2
Large Washer
2. Tighten nut
Torque nut to 30 ft .lbs. ( 41Nm)
Small Washer
Steering Bolt
Large Washer
Lock Nut
10mm Steering Bolt
10mm Large Washers
10mm Small Washer
10mm Lock Nut
Top Bracket
Steering Neck
Bottom Bracket

Coleman CT200U Specifications

General

Engine	196cc
Horsepower	6.5 hp
Starting System	Recoil Start
Frame	Steel
Weight Capacity	200 lbs
Transmission	Automatic centrifugal clutch
Tires	19x7-8
