5.2 Adjust paper brake powert
The paper brake is adjusted to an optimal value at the factory. Any necessary
adjustments are to be made from the outside with the M3-screw (1) inside of
the label-end case of the dispenser.
Screw in = higher brake power
Screw out = lower brake power
5.3 Adjust coupler power of rewinder
The coupler power of the rewinder spindle is adjusted at the factory. Any ne-
cessary adjustments can be made as follows:
Take off rewinder spindle (1) after loosening M5-screw (2).
Screw in M8-screw (3) = harder coupler power.
Screw out = softer coupler power.
1
1
3
2
