COMAG SC25-S - Default Chapter; Overview of Equipment

3
Overview of equipment
Front side of the receiver
1
IR Remote Connection for the infrared sensor to
receive the signals of the remote control.
2
DC IN 12V Connection 12V/power pack
Rear side of the receiver
1
LNB IN LNB connection for the antenna cable
2
IF-OUT LNB connection for a second satellite
receiver
3
TV (output) SCART connection for the TV set
