Gen V1, V2, V3 ph-N (triple bargraph)
Gen I1, I2, I3 (triple bargraph)
IL-CU Analog inputs screen
Oil pressure (single bargraph)
Water temperature (single bargraph)
Fuel level (single bargraph)
Battery voltage (single bargraph)
IL-CU binary inputs
BI1 to BI6
IL-CU binary outputs
BO1 to BO6
ECU state
ECU YellowLamp
ECU RedLamp
WaitToStart
Hint:
This screen is shown/hidden depending on whether the ECU is configured or not.
*ECUValues
Oil press
Water temp
PercLoadAtCS
Boost pressure
ManifoldTemp
Fuel rate
Hint:
This screen is shown/hidden depending on whether the ECU is configured or not.
Gen-set power screen
Active power (total and per phase)
Power factor (total and per phase)
React power (total and per phase)
Appar power (total and per phase)
Statistic
Run hours
Number of starts
*Kilowatt-hours kWh (total)
*Reactive power hours kVAh (total only)
NextServTime
*ECU AlarmList
Diagnostic messages are read from ECU and displayed in this second alarm list. For Standard J1939
engines SPN (Suspect Parameter Number), FMI (Failure Mode Identifier) and OC (Occurrence
Counter) are shown together with verbal description if available.
Following image shows displaying of ECU alarms in the second alarm list. The additional information
for the row selected by cursor is on the last row (SPN, OC and FMI codes).
If the verbal description of alarm is not available, the SPN (decimal and hexadecimal) is displayed.
InteliLite – MRS10/11/15/16, SW version 2.2, ©ComAp – November 2004 47
