3.3.5 POLE MOUNTING OF MOUNTING RACK
 The equipment can be mounted on a pole of about 60~75mm in diameter.
 Insert and tighten the two U bolts to secure the mounting rack onto the pole.
 The remaining installation to secure the enclosure to the mounting rack is identical to wall mounting.
Mounting Rack
U Bolt M10X85X110
Enclosure
M8X20 Hex Bolt
Pole
Figure 6: Pole Mounting Overview
3.3.6 DRIP-LOOP
Comba recommends that every horizontal cable entry to the equipment forms a 'U' before its entry to the
equipment. Water on the cable will drip down at the bottom of the loop and will not accumulate at the
equipment connectors.
