INSTALLATION GUIDE FOR RX-7W22, II2
2.2 EQUIPMENT LAYOUT
Shown below is the internal layout of the PS BDA.
Figure 3: Layout of the PS BDA
Power Supply Unit
800MHz Integrative Module
Master Digital Board
Duplexer
Duplexer
Slave Digital Board
700MHz Integrative Module
