Art. CA2200
GENERAL DATA
Type Monolithic
Height (mm) 172
Width (mm) 100
Depth (mm) 28
Product colour Grey RAL 9006
Surface mounting Yes
COMPATIBLE SYSTEMS
Simplebus2 audio with power supply unit art. 1210/1210A
ELECTRICAL SPECIFICATIONS
Type of power supply Power supply via video entry bus
Power supply voltage 33 VDC
Absorption in standby 0.62
Maximum absorption (W) 0.62
HARDWARE CHARACTERISTICS
Call type Buttons
Type of buttons Mechanical
Number of buttons (no.) 16
Backlighting colour White
SETTINGS
Backlighting brightness Ye s
ENVIRONMENTAL AND CONFORMITY SPECIFICATIONS
IP protection rating IP54
IK anti-vandal protection rating IK08
Operating temperature (°C) -25 to 55
Operating humidity (max RH - %) 25 to 95
Environmental class IV
CE certification RoHS II - 2011/65/EU (EN 50581:2012), EMC 2014/30/EU (EN
61000-6-1:2007, EN 61000-6-3:2007+A1:2011)
ELECTRICAL SPECIFICATIONS
Type of power supply Power supply via video entry bus
Power supply voltage 33 VDC
Absorption in standby (W) 1.7
Maximum absorption (W) 7.6
HARDWARE CHARACTERISTICS
Call type Buttons
Type of buttons Mechanical
Number of buttons (no.) 8
Backlighting colour White
Terminals L L COM DO RTE C NO NC SE+ SE
Removable terminals Yes
Number of inputs (no.) 2
Number of outputs (no.) 1
SETTINGS
Backlighting brightness Ye s
Loudspeaker volume Yes
ENVIRONMENTAL AND CONFORMITY SPECIFICATIONS
IP protection rating IP54
IK anti-vandal protection rating IK08
Operating temperature (°C) -25 to 55
Operating humidity (max RH - %) 20 to 95
Environmental class IV
CE certification RoHS II - 2011/65/EU (EN 50581:2012), EMC 2014/30/EU (EN
61000-6-1:2007, EN 61000-6-3:2007+A1:2011)
