Comelit Ciao Series User Manual

5
Technical features
Art. CA2100P
Art. CA2200P
MAIN FEATURES
Type of power supply BUS
Power supply voltage 27÷34 Vdc (BUS)
Min. absorption (W) 1.7W
Max. absorption (W) 7.6W
Terminals L L COM DO RTE C NO NC SE+ SE-
Removable terminals Yes
Microphone electret
Loudspeaker 8ohm 0.2W
Loudspeaker volume control Yes
Brightness control Yes
IP rating IP 54
IK rating IK 08
Operating temperature -25 °C ÷ +55 °C
Operating relative humidity 25 ÷ 75%
Width 100 mm
Height 172 mm
Depth 28 mm
COMPATIBILITY
SB2 Audio System Yes
MAIN FEATURES
Type of power supply BUS
Power supply voltage 27÷34 Vdc (BUS)
Min. absorption (W) 0.62W
Max. absorption (W) 0.62W
Brightness control Yes
IP rating IP 54
IK rating IK 08
Operating temperature -25 °C ÷ +55 °C
Operating relative humidity 25 ÷ 75%
Width 100 mm
Height 172 mm
Depth 28 mm
