Eurokey NEXT – Quick Guide
36
5. Installation and Connections
5.1 Cashless system installation
Cashless system is extremely adaptable and it can be easily installed in front side or
back-box through the appropriate adaptation grill.
In the pictures below are shown the holes to do on the device based on the choosen
installation mode.
FRONT MOUNTING
Figure 7
Reader with traffic lights signal with 3 led and infrared interface for collecting audit
data.
BACKPLANE MOUNTING
Figure 8
