Eurokey NEXT – Quick Guide
38
5.3.2 Installing KPD card
The KPD card makes it possible to
manage up to 2 services
simultaneously: 2 relay outputs for
service activation and 4 inputs, of
which 2 to choose the service and 2
for inhibit/busy signal. The card is
equipped with a network
transformer.
Figure 11
The specified data of the transformer on the KPD is 230 Vac/24
Vac (15W). The overall consumption of the connected peripherals
must be lower than the limits set by the specified data.
5.3.3 Installing RM 925 card
This card is only provided to
guarantee compatibility with previous
systems and does not allow
connection of any peripheral.
Figure 12
