For example:
MPEG-1 file
• Encoding rate = 1.5Mbit/s (1,572,864 bit/s)
• Playback time = 60s (1 minute)
• File size ~ 11MByte
MPEG-2 file
• Encoding rate = 6Mbit/s (6,291,456 bit/s)
• Playback time = 60s (1 minute)
• File size ~ 45MByte
7. RS-232 Commands on ProPLAY
7.1 Connection
Connect your ProPLAY through RS-232 port. The baud rate setting of 9600 N81
must be used. Note: The ProPLAY needs special firmware for this function.
7.2 Command Code
All the command codes are stored and defined in the barcode.ini file which is
generated by ProPLAY Studio. Please see the following example:
[Barcode]
BC1=0001
BC2=0002
BC3=0003
BC4=0004
BC5=0005
BC6=0006
BC7=0007
BC8=0008
[0001]
rs232key=1
action=1
[0002]
rs232key=1
action=2
[0003]
rs232key=1
action=3
[0004]
rs232key=1
action=4
[0005]
rs232key=1
action=5
[0006]
rs232key=1
action=6
[0007]
rs232key=1
action=7
[0008]
rs232key=1
action=8
The above barcode.ini file contains eight command codes which match with existing function of 8
buttons (PLAY, STOP, PAUSE, REPEAT, NEXT, VOL DN, VOL UP and MUTE).
