Hook up to power & test motor functions before nishing the re-assembly.
14.
Replace push pad by placing over activating arms &
pushing down (A) then back towards end of device (B)
15.
A B
Slide baseplate back into housing being careful of
pinching motor/REX wires.
16.
US customer support 1-888-622-2377 | www.commandaccess.com | CA customer support 1-855-823-3002
Installation Instructions
