Commax CMP-2BC User Manual

513-11, Sangdaewon-dong, Jungwon-gu, Seongnam-si, Gyeonggi-do, Korea
Int’l Business Dept. Tel. : +82-31-7393-540~550 Fax. : +82-31-745-2133
Web site : www.commax.com
• Thank you for purchasing COMMAX products.
• Please carefully read this User’s Guide (in particular, precautions for safety) before using a product and follow
instructions to use a product exactly.
• The company is not responsible for any safety accidents caused by abnormal operation of the product.
Printed In Korea / 2014.10.104
PM982BC4BC10

Commax CMP-2BC Specifications

General

Voltage	DC 12V
Power Consumption	232mA ( MAX )
Wiring	6 WIRES (POLARITY, Using with Converter unit)
Communication	DUPLEX
Camera Angle	HORIZONTAL 62°, VERTICAL 46°
Camera Module	C-MOS
Scan Frequency	PAL HORIZONTAL : 15.735KHz/60Hz, VERTICAL : 15, 625KHz/50HZ
Temperature	-20°C ~ +50°C

Weight and Dimensions

Demension	CMP-2BC / 4BC : 130(W) X 315(H) X 38(D)
