Commax CMP-2BC User Manual

1
Table of Contents
1. Greetings
●
Thank you for Purchasing COMMAX Products
●
Please carefully read this User's Manual (in particular, precautions for safety) before using a
product and follow instructions to use a product exactly.
1. Greetings ...............................................................................................1
2. Warnings and Cautions...........................................................................2
3. Overview .................................................................................................4
4. How to use ............................................................................................5
5. Wiring .....................................................................................................5
6. Part List ................................................................................................7
7. Installation ..............................................................................................7
8. Specification ...........................................................................................8

Commax CMP-2BC Specifications

General

Voltage	DC 12V
Power Consumption	232mA ( MAX )
Wiring	6 WIRES (POLARITY, Using with Converter unit)
Communication	DUPLEX
Camera Angle	HORIZONTAL 62°, VERTICAL 46°
Camera Module	C-MOS
Scan Frequency	PAL HORIZONTAL : 15.735KHz/60Hz, VERTICAL : 15, 625KHz/50HZ
Temperature	-20°C ~ +50°C

Weight and Dimensions

Demension	CMP-2BC / 4BC : 130(W) X 315(H) X 38(D)
