CommScope CAP M2 35LT/35HT F-AC User Manual

M0203AHA_uc CommScope ERA
®
CAP M2 with Fiber Interface
© August 2022 CommScope, Inc. Page 7
Document Overview
Maximum Output Power Levels
Table 3 lists the frequencies and maximum power output for bands supported in the CAP M2 variants.
Required Antenna Distances
Table 3. Maximum Power Output by Frequency
Band DL Frequency Range
Power Output
[dBm]
35LT 3410 – 3640 MHz 35
35HT 3570 – 3800 MHz 35
C-Band 3700 – 3980 MHz 35
Table 4. Minimum Antenna Distances
Model
Antenna Gain
Without Cable Loss
(dBi)
Minimum Distance DL
FCC ISED
meters inches meters inches
CAP M2 C-Band 15 1.784 70.236 2.751 108.307
