4. Commissioning
Page 20 MF0150A9A_prel.docx Manual for ION-M23 SDARS 3-Sector
figure 4-3 Pole mounting (metric dimensions)
G0764M6
Lock for folding
screw band ES 119
TESPA screw band,
stainless, 11 mm
Optical
Remote Unit
Washer DIN 125
Form B Ø 8.0
Lock washer for M8.0 DIN 127
A2 Form B
Hexagon nut M8
DIN 934
Pole
Pole
Pole-mounting
bracket
Ø
1
4
0
Ø
4
0
