7. Appendix
Page 44 MF0150A9A_prel.docx Manual for ION-M23 SDARS 3-Sector
7.2. Specifications
7.2.1. Electrical Specifications
Electrical
Power
supply
Mains power,
AC
nominal 100 Vac to 240 Vac
operating 85 Vac to 264 Vac
Mains power,
DC
nominal 48 Vdc to 60 Vdc
operating 36 Vdc to 72 Vdc
Power
consumption
max. temp., fully loaded 215 watts
room temp., idle 90 watts
Optical Link
Optical link connectors E2000/APC 8
Optical return loss 45 dB min. °
Fibre type Single mode E9/125 µm
Optical link budget 0 dB to 10 dB
All data is subject to change without notice.
7.2.2. SW Requirements
Minimum SW requirements for basic support: ION-M SW V7.50
7.2.3. Mechanical Specifications
Height, width, depth * 831 x 156 x 147 mm (32.7 x 6.1 x 5.8 in)
Weight, 22 kg (48 Ib)
* Spacing required 40 mm (1.58 in) around unit
All data is subject to change without notice.
7.2.4. Environmental and Safety Specifications
Note: For detailed information, please refer to the Environmental and Safety
Specifications leaflet of the supplier, related to ETS 300 019 (European
Telecommunication Standard).
Operating temperature range -33° C to +55° C
Ingress protection IP67
All data is subject to change without notice.
