5. System Operation
Page 12 PowerShift User Manual Version B
5.4. DIP Switch and Data Interface
As shown below, each base unit has a DIP switch and RJ45 interface ports.
Figure 5-4 DIP Switch and Data Interface Ports
DIP Switches
a. The DIP switches are not for customer use, they should be left in the down
position (factory default setting)
RJ45 Data Ports
a. The RJ45 data ports provide the communication connection point for a
Windows PC running the GUI software.
