Page #14 background image
5. System Operation
Page 14 PowerShift User Manual Version B
Circuit
1, 2 or 3
LED
Module
“X” LED
Alarm
Condition
(GUI & Relay)
Description
Green
Blink
Solid
Green
None
(<30 sec)
-Or-
Major
(>60 sec)
Circuit is performing line resistance measurement
Nominal condition (no alarm) 30 second duration
- Circuit is measuring the line resistance, it takes ~30 seconds to complete
- Occurs whenever circuit input power is applied or is cycled off/on
- Remote is not powered during this time
- After ~30 seconds the circuit LED should change to solid green
- No alarm is raised during or after if the measurement is successful
Alarm condition (Major)line resistance measurement unsuccessful
- If circuit LED continues to blink green after 60 seconds this indicates the
module could not successfully measure the line resistance of the affected
circuit
- A major alarm condition is raised
- PowerShift will use a default line resistance (0.15 Ohms) in order to
provide voltage to the radio so that it can operate
Possible cause Capacitive Jumper disconnected or failed
- If there is no power to the radio there may be a break in the trunk cable
or a failure in the capacitive jumper; perform a continuity check
- If there is power to the radio then the capacitive jumper may have failed
in a closed condition
