*25
* 25
*25
*25
* Angle may be limited by
direct mount radio equipment
Limits of strut position
for attachment to
tower member
IDEAL = 0
MAXIMUM = 25
Veiw show below is intended as a guide for strut alignment.
Strut must be attached to appropriate structural mounting point.
Strut angle must not exceed maximum specified.
Failure to install the strut as instructed may result in mechanical failure of the antenna.
Page 29 of 30
7722483
