Table 1 Supplied Equipment and Tools
Page 6 of 30
7722483
EQUPMENT AND TOOLS
SECTION 3 INSTALLATION
INSTRUCTIONS
Item Qty Description Contained in Kit Part No
A 1 Reflector
B 1 Shield Set
C 1 Radome
D 1 Feed (frequency dependant)
D1 6ft Feed Hardware Kit 7625043
4 M4 x 16lg SHCS, sst, pass
4 M4 Lock Washer, sst, pass
1 Conductive Grease (tube)
2 Gloves
D2 Vertex Plate Kit (6GHz & 11GHz only) 7714550-FR-KIT
2 Vertex Plate
4 M4 x 10lg SHCS, sst, pass
E Elevation Pivot Bar - Top
F Vertical Support Channel
G Mount Kit - 6ft 7770572
G1 1 Elevation Pivot Bar - Bottom
G2 3 Spacer Plate
G3a 1 Elevation Pivot Bracket - Top Right
G3b 1 Elevation Pivot Bracket - Top Left
G4 1 Elevation Pivot bracker - Bottom
G5 1 Safety Bracket
H Shield Hardware Kit 7719422
H1 62 M6 x 20 Hex Hd Screw, sst, pass
124 M6 Washer, sst, pass
62 M6 Lock Washer, sst, pass
62 M6 Nut, sst, pass
H2 40 M6 x 25 Skt Hd Cap Screw, sst, pass
40 M6 Large Washer, sst, pass
J Mount Hardware Kit 7714342
J1 3 M16 U-Bolt c/w Nuts & Washers
J2 4 M12 x 40lg Carriage Bolt
4 M12 Nut, stl, galv
4 M12 Lock Washer, stl, galv
4 M12 Washer, stl, galv
4 M16 Washer, stl, galv
J3 1 M16 Eye Bolt, stl, galv
2 M16 Washer, stl, galv
2 M16 Nut, stl, galv
1 M12 x 45lg Hex Hd Screw, stl, galv
1 M12 Lock Washer, stl, galv
1 M12 washer, stl, galv
1 M12 Nut, stl, galv
J4 2 M16 x 45lg Hex Hd Screw, stl, galv
2 M16 Lock Washer, stl, galv
4 M16 Washer, stl, galv
2 M16 Nut, stl, galv
J5 9 M10 x 35lg Hex Hd Screw, sst, pass
9 M10 Lock Washer, sst, pass
9 M10 Washer, sst, pass
