CommScope ValuLine VHLP Series User Manual

Table 1 Supplied Equipment and Tools
Page 7 of 30
7722483
EQUIPMENT AND TOOLS
SECTION 3 INSTALLATION
INSTRUCTIONS
Item Qty Description Contained in Kit Part No
K Strut Hardware Kit 7721920
K1 1 Spacer Plate
1 Brce Rod Attachment Bracket
1 M12 X 35lg Hex Hd Screw, stl, galv
1 M12 Lock Washer, stl, galv
1 M12 Washer, stl, galv
3 M10 x 35lg Hex Hd Screw, sst, pass
3 M10 Lock Washer, sst, pass
3 M10 Washer, sst, pass
K2 Azimuth Adjuster Assembly P99915 (supplied assembled)
1 Azimuth Adjuster Bracket
1 Adjuster Plate Bracket
2 Clamp Bracket
1 Swivel Plate
1 M16 x 390lg Eye Bolt, stl, galv
2 M12 U-Bollt c/w Nuts and Washers
1 M12 x 180lg Stud, stl, galv
1 M12 X 140lg Hex Hd Screw, stl, galv.
1 M12 x 60lg Skt Hd C'sk Screw, stl, galv
9 M12 Nut, stl, galv
7 M12 Washer, stl, galv
1 M12 Lock Washer, stl, galv
1 M12 Washer, stl, galv
L 1 Brace Rod
