Compak E6 OD - Grinder Regulation

K06307 | v. 22/07/2015 | Ref. quality process 002/03 | ORIGINAL INSTRUCTIONS
9
8. REGULATION
8.1.Adjustingthelowerportaltersupport
Inordertoensuretheproperdistributionofgroundcoffeeintheportalter,while
supporting the portalter in a hands-free position during dosing, it is possible to
adjusttheheightofthelowerportaltersupport( ).
To do this adjustment operation:
1. Loosen the screw ( ) on the lower support ( ) by using the Allen Key included
with your grinder.
2. Adjustthesupport to thedesired heightusingthe portalteras the pointof
reference.
3. Tighten the screw ( ) with the Allen Key provided (Fig. 1).
NOTE: Iftheadjustmentisextreme(toohighortoolow),difcultiesinoperatingthe
dosis button might occur.
