6. EXTERNAL COMPONENTS
1
Hopper lid
2
Coffee bean
hopper
3
Hand
protector
4
Coffee bean
shutter
7
Control knob
10
Support
adjustment
screw
9
Portalter
spring clamp
13
Three position
main switch
14
Display
8
Dose lling
button
12
Exit
Chute
11
Scale
6
Coffee
collection
tray
5
Safety
Screw
16
Upper
holder
support
17
Filling
button
